CCS差壓開關6900DZE系列
CCS緊湊加強型防爆差壓開關 6900DZE系列6900DZE接口尺寸1/4"接口材料不銹鋼隔膜材料聚丁鈉橡膠最大允許壓力(KG)設定壓力范圍(KG)降壓設定范圍(KG)壓力開關型號SPDTDPDT27.590.08～1.240.03～1.196900DZEB6900DZEM827.590.41～5.170.14～4.906900DZE106900DZEM10SERIES:6900DZE
詳細介紹
CCS緊湊加強型防爆差壓開關 6900DZE系列
| |||||||||||||||||
 | |||||||||||||||||
SERIES:
- 6900DZE*
ADJUSTABLE SET POINT RANGE:
- DIFFERENTIAL PRESSURE:
- .4 to 75 PSID
- 0.028 to 5.17 bar
- 2.76 to 517 kPa
OPERATING TEMPERATURE:
Temperature limits change with O-ring selection.
- -40° to 186°F
- -40° to 86°C
