CCS壓力開關 604G3
CCS壓力開關 604G3604GZ接口尺寸1/2"接口材料316SS隔膜材料聚丁鈉橡膠最大允許壓力(MPa)設定壓力范圍(MPa)壓力開關型號SPDTDPDT3.4480.006～0.121604GZ1604GZM120.6900.041～0.490604GZ2604GZM220.6900.083～0.979604GZ11604GZM1120.6900.207～2.448604GZ36
詳細介紹
CCS壓力開關 604G3
604GZ
接口尺寸 | 1/2" |
接口材料 | 316SS |
隔膜材料 | 聚丁鈉橡膠 |
最大允許壓力(MPa) | 設定壓力范圍(MPa) | 壓力開關型號 | |
SPDT | DPDT | ||
3.448 | 0.006～0.121 | 604GZ1 | 604GZM1 |
20.690 | 0.041～0.490 | 604GZ2 | 604GZM2 |
20.690 | 0.083～0.979 | 604GZ11 | 604GZM11 |
20.690 | 0.207～2.448 | 604GZ3 | 604GZM3 |
20.690 | 2.069～6.517 | 604GZ5 | 604GZM5 |
20.690 | 6.207～14.828 | 604GZ7 | 604GZM7 |
604GZ-7011
接口尺寸 | 1/2" |
接口材料 | 316SS |
隔膜材料 | 316SS |
最大允許壓力(MPa) | 設定壓力范圍(MPa) | 壓力開關型號 | |
SPDT | DPDT | ||
3.448 | 0.010～0.117 | 604GZ1-7011 | 604GZM1-7011 |
20.690 | 0.062～0.476 | 604GZ2-7011 | 604GZM2-7011 |
20.690 | 0.124～0.952 | 604GZ11-7011 | 604GZM11-7011 |
20.690 | 0.310～2.379 | 604GZ3-7011 | 604GZM3-7011 |
20.690 | 2.069～6.379 | 604GZ5-7011 | 604GZM5-7011 |
20.690 | 6.207～14.621 | 604GZ7-7011 | 604GZM7-7011 |
34.483 | 13.793～21.552 | 604GZ9-7011 | 604GZM9-7011 |
34.483 | 19.310～31.379 | 604GZ10-7011 | 604GZM10-7011 |
接點容量
|  | ||||||||||||||||||||||
SERIES:
- 604G*
ADJUSTABLE SET POINT RANGE:
- 0.3 to 5000 PSIG
- 0.02 to 345 bar
- 2.07 to 34474 kPa
OPERATING TEMPERATURE:
Temperature limits change with O-ring selection.
- -40° to 186°F
- -40° to 86°C
